Router uptime is 3 minutes This product contains cryptographic features and is subject to United A summary of U.S. laws governing Cisco cryptographic products may be found at: If you require further assistance please contact us by sending email to Suite License Information for Module:'esg' -------------------------------------------------------------------------------- AdvUCSuiteK9 None None None ----------------------------------------------------------------- cisco ISR4451-X/K9 (2RU) processor with 1795999K/6147K bytes of memory. Configuration register is 0x2102 Router# +++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++ NAME: "Chassis" DESCR: "Cisco ISR4451 Chassis" NAME: "Power Supply Module 0" DESCR: "450W AC Power Supply for Cisco ISR4450 ISR4350" NAME: "Fan Tray" DESCR: "Cisco ISR4450 ISR4350 Fan Assembly" NAME: "module 0" DESCR: "Cisco ISR4451 Built-In NIM controller" NAME: "NIM subslot 0/1" DESCR: "NIM-ES2-4" NAME: "NIM subslot 0/0" DESCR: "Front Panel 4 ports Gigabitethernet Module" NAME: "module 1" DESCR: "Cisco ISR4451 Built-In SM controller" NAME: "module 2" DESCR: "Cisco ISR4451 Built-In SM controller" NAME: "module R0" DESCR: "Cisco ISR4451 Route Processor" NAME: "module F0" DESCR: "Cisco ISR4451 Forwarding Processor" Router#sh env all Router#
Router#show ver
Cisco IOS XE Software Version 16.06.04
Cisco IOS Software [Everest] ISR Software (X86_64_LINUX_IOSD-UNIVERSALK9-M) Version 16.6.4 RELEASE SOFTWARE (fc3)
Technical Support: http://www.cisco.com/techsupport
Copyright (c) 1986-2018 by Cisco Systems Inc.
Compiled Sun 08-Jul-18 04:33 by mcpre
Cisco IOS-XE software Copyright (c) 2005-2018 by cisco Systems Inc.
All rights reserved. Certain components of Cisco IOS-XE software are
licensed under the GNU General Public License ("GPL") Version 2.0. The
software code licensed under GPL Version 2.0 is free software that comes
with ABSOLUTELY NO WARRANTY. You can redistribute and/or modify such
GPL code under the terms of GPL Version 2.0. For more details see the
documentation or "License Notice" file accompanying the IOS-XE software
or the applicable URL provided on the flyer accompanying the IOS-XE
software.
ROM: IOS-XE ROMMON
Uptime for this control processor is 4 minutes
System returned to ROM by Reload Command
System image file is "bootflash:isr4400-universalk9.16.06.04.SPA.bin"
Last reload reason: Reload Command
States and local country laws governing import export transfer and
use. Delivery of Cisco cryptographic products does not imply
third-party authority to import export distribute or use encryption.
Importers exporters distributors and users are responsible for
compliance with U.S. and local country laws. By using this product you
agree to comply with applicable laws and regulations. If you are unable
to comply with U.S. and local laws return this product immediately.
http://www.cisco.com/wwl/export/crypto/tool/stqrg.html
export@cisco.com.
Suite Suite Current Type Suite Next reboot
--------------------------------------------------------------------------------
FoundationSuiteK9 None None None
securityk9
appxk9
uck9
cme-srst
cube
Technology Package License Information:
Technology Technology-package Technology-package
Current Type Next reboot
------------------------------------------------------------------
appxk9 None None None
uck9 None None None
securityk9 None None None
ipbase ipbasek9 Permanent ipbasek9
Processor board ID FGL224730JC
1 Virtual Ethernet interface
8 Gigabit Ethernet interfaces
32768K bytes of non-volatile configuration memory.
4194304K bytes of physical memory.
7081983K bytes of flash memory at bootflash:.
0K bytes of WebUI ODM Files at webui:.
Router#sh lic all
License Store: Primary License Storage
StoreIndex: 0 Feature: ipbasek9 Version: 1.0
License Type: Permanent
License State: Active In Use
License Count: Non-Counted
License Priority: Medium
StoreIndex: 1 Feature: throughput Version: 1.0
License Type: Permanent
License State: Active In Use
License Count: Non-Counted
License Priority: Medium
License Store: Built-In License Storage
StoreIndex: 0 Feature: appxk9 Version: 1.0
License Type: EvalRightToUse
License State: Active Not in Use EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 1 Feature: uck9 Version: 1.0
License Type: EvalRightToUse
License State: Active Not in Use EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 2 Feature: securityk9 Version: 1.0
License Type: EvalRightToUse
License State: Active Not in Use EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 3 Feature: FoundationSuiteK9 Version: 1.0
License Type: EvalRightToUse
License State: Active Not in Use EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 4 Feature: AdvUCSuiteK9 Version: 1.0
License Type: EvalRightToUse
License State: Active Not in Use EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
StoreIndex: 5 Feature: cme-srst Version: 1.0
License Type: EvalRightToUse
License State: Active Not in Use EULA not accepted
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: 0/0 (In-use/Violation)
License Priority: None
StoreIndex: 6 Feature: throughput Version: 1.0
License Type: EvalRightToUse
License State: Inactive
Evaluation total period: 8 weeks 4 days
Evaluation period left: 8 weeks 4 days
Period used: 0 minute 0 second
License Count: Non-Counted
License Priority: None
Router#sh inv
INFO: Please use "show license UDI" to get serial number for licensing.
+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
PID: ISR4451-X/K9 VID: V08 SN: FGL224730JC
PID: PWR-4450-AC VID: V03 SN: DCC2241L2E8
PID: ACS-4450-FANASSY VID: SN:
PID: ISR4451-X/K9 VID: SN:
PID: NIM-ES2-4 VID: V01 SN: FOC22458CYU
PID: ISR4451-X-4x1GE VID: V01 SN:
PID: ISR4451-X/K9 VID: SN:
PID: ISR4451-X/K9 VID: SN:
PID: ISR4451-X/K9 VID: V08 SN: FOC22439CJY
PID: ISR4451-X/K9 VID: SN:
Sensor List: Environmental Monitoring
Sensor Location State Reading
Temp: Temp 1 P0 Normal 29 Celsius
Temp: Temp 2 P0 Normal 36 Celsius
Temp: Temp 3 P0 Normal 40 Celsius
V: PEM Out P0 Normal 12410 mV
I: PEM In P0 Normal 1 A
I: PEM Out P0 Normal 5 A
P: In pwr P0 Normal 71 Watts
P: Out pwr P0 Normal 60 Watts
RPM: fan0 P0 Normal 3284 RPM
RPM: fan0 P2 Normal 4405 RPM
RPM: fan1 P2 Normal 4429 RPM
RPM: fan2 P2 Normal 4279 RPM
RPM: fan3 P2 Normal 4479 RPM
P: pwr P2 Normal 4 Watts
Temp: Inlet 1 R0 Normal 25 Celsius
Temp: Inlet 2 R0 Normal 25 Celsius
Temp: Outlet 1 R0 Normal 30 Celsius
Temp: Outlet 2 R0 Normal 32 Celsius
Temp: core-A R0 Normal 43 Celsius
Temp: core-B R0 Normal 41 Celsius
Temp: core-C R0 Normal 44 Celsius
V: 12v R0 Normal 12466 mV
V: 5v R0 Normal 5132 mV
V: 3.3v R0 Normal 3344 mV
V: 3.0v R0 Normal 3015 mV
V: 2.5v R0 Normal 2439 mV
V: 1.05v R0 Normal 1052 mV
V: 1.8v R0 Normal 1811 mV
V: 1.2v R0 Normal 1234 mV
V: Vcore-C R0 Normal 1157 mV
V: 1.1v R0 Normal 1110 mV
V: 1.0v R0 Normal 1017 mV
V: 1.8v-A R0 Normal 1787 mV
V: 1.5v-A R0 Normal 1513 mV
V: 1.5v-C1 R0 Normal 1532 mV
V: 1.5v-B R0 Normal 1526 mV
V: Vcore-A R0 Normal 1015 mV
V: 1.5v-C2 R0 Normal 1497 mV
V: Vcore-B1 R0 Normal 830 mV
V: Vcore-B2 R0 Normal 806 mV
V: 0.75v-B R0 Normal 762 mV
V: 0.75v-C R0 Normal 770 mV
I: 12v R0 Normal 5 A
P: pwr R0 Normal 61 Watts
P: pwr: Pwr 0/1 Normal 3 Watts
